VZ5000 Specifications
| Product | |
|---|---|
| Model | VZ5000 |
| Part Number | 77D0300 |
| List price (per unit) | $1,499 USD |
| Performance | |
|---|---|
| Processor | NVIDIA Jetson Xavier NX |
| Storage | 16GB |
| Memory | 8GB (128 bit) |
| AI Performance | Up to 21 TOPS |
| Security | |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Secure boot | Yes |
| OS update | Yes |
| Connectivity | |
|---|---|
| Local Area Network (LAN) | 1 x 10/100/1000 Mbps |
| Wireless Local Area Network (WLAN) | Wi-Fi 5 (2.4Ghz & 5Ghz) |
| Personal Area Network (PAN) | 1 x 1 Bluetooth Low Energy (BLE) |
| Local Ports | 2 x USB-A (2.0) 1 x USB-C (3.0) |
| Audio input | 1 x internal microphone |
| Audio output | 1 x 3.5mm connector |
| Video output | 1 x HDMI 2.0 (4K out) |
| General Purpose Input/Output (GPIO) | 2 x Relays 2 x 7 DIO |
| External storage | 1 x microSD |
| Antennas | 2 x RP-SMA |
| Environment | |
|---|---|
| Operating temperature | 32F (0C) to 104F (40C) |
| Operating humidity | 95% @ 104F(40C) - non-condensing |
| Storage temperature | -40F (-40C) to 140F (60C) |
| Cooling | Forced air |
| Power | |
|---|---|
| Power supply | 45W external |
| Input voltage | 19V |
| Certifications | |
|---|---|
| Certifications | CB, CE, UL, FCC |
| Software | |
|---|---|
| Docker containers | 20.10.25-ce |
| Compatible base container images | nvcr.io/nvidia/deep-stream-l4t:6.2-base nvcr.io/nvidia/l4t-pytorch:r35.2.1-pth2.0-py3 nvcr.io/nvidia/l4t-tensor-flow:r35.3.1-tf2.11-py3 nvcr.io/nvidia/l4t-ml:r35.2.1-py3 |
| System OS | Poky Linux (Kirkstone) |
| NVIDIA L4T compatibility | Jetson Linux 35.5.0 |
| Packaging | |
|---|---|
| Dimensions (without antennas) | 8.3" x 8.3" x 3.1" (211 x 211 x 79mm) |
| Weight | 3.3 lbs (1.51kg) |
| Box Contents | 1 x Optra Edge device 2 x antennas 1 x power supply 1 x publications |
